OEM Medical Instrument Parts For Medical device A380 High Pressure Die Casting Parts
Overview
| Name | China Factory Customized Aluminum Die Casting Medical devide Parts |
| Material | ADC12, A380, AlSi9Cu, ADC10 ,A413 ,B390 |
| Dimension | Mini 80*80 mm, Max800*800 mm |
| Technology | High Preressure Die Casting, CNC, CMM Measure, Painting, X-Ray Detection |
Processing | 1, Sign Drawing (General clients provide the drawing or samples) 2, Opening the Mold 3, Die Casting ( Aluminium or Aluminium Alloy) 4, Precision Machining (Burring, Lathe, Milling, etc) 5, Surface treatment: Polishing, Electroplating, Sandblasting, Anodizing 6, Inspection and Packing |
| Application | Automobile 26%, Telecom 21%, Industry 18%, Medical device 12% ,Lighting 15%, Other 8% |
Customized Die mold steps.
1. Customers will provide 3D drawings or sample inquiry, and we
will quote according to 3D drawings or samples.
2. Negotiations include mold price, mold quality, mold material,
mold cavity material, mold size, surface effects, technical
requirements, mold life, warranty period, product weight, product
cost, delivery time, logistics mode, payment mode, etc.
3. Confirm the order. Proforma invoice or commercial invoice.
4. T/T deposit. 50% T/T in advance ,balance before shipment.
5. DFM (Design For Manufacturing), Ensure quality. Mould design,
mould drawing confirmation.
6. Mold processing. Feedback the processing progress every week, we
will show you the pictures of mold processing.
7. Sample confirmation. Express sample, confirm sample, mass
production.
8. Product packaging. Wooden case, carton or custom made.
9. Delivery. By Sea, By air, etc. Pay the balance.
Raw Material Datasheet
| ALUMINUM DIE CASTING ALLOYS | |||||
| (Composition, Properties & Characteristics) | |||||
| ALLOY COMPOSITION (% max or range) | A360 (ADC3) | A380 (ADC10) | A383 (ADC12) | A390 (ADC14) | A413 (A13) |
| Silicon | 9~10 | 7.5.-9.5 | 9.5-11.5 | 16-18 | 11~13 |
| Iron | 1.3 | 1.3 | 1.3 | 1.3 | 1.3 |
| Copper | 0.6 | 3/4 | 2/3 | 4/5 | 1 |
| Manganese | 0.35 | 0.5 | 0.5 | 0.5 | 0.35 |
| Magnesium | 0.40-0.60 | 0.1 | 0.1 | 0.45- 0.65 | 0.1 |
| Nickel | 0.5 | 0.5 | 0.3 | 0.1 | 0.5 |
| Zinc | 0.5 | 3 | 3 | 1.5 | 0.5 |
| Tin | 0.15 | 0.35 | 0.15 | 0.2 | 0.15 |
| Titanium | - | - | - | 0.2 | - |
| Total others | 0.25 | 0.5 | 0.5 | 0.2 | 0.25 |
| Aluminum | Bal. | Bal. | Bal. | Bal. | Bal. |
| PROPERTIES | A360 | A380 | A383 | A390 | A413 (A13) |
| Ultimate Tensile (ksi) | 46 | 47 | 45 | 40.5 | 42 |
| Tensile Yield Strength (ksi) | 24 | 23 | 22 | 35 | 19 |
| Elongation (% in 2" G.L.) | 3.5 | 3.5 | 3.5 | 3.5 | |
| Hardness (BHN) | 75 | 80 | 75-80 | 85 | 120 |
| Shear Strength (ksi) | 26 | 27 | 25 | - | 29 |
| Charpy impact strength (ft.lb.—unnotched) | 4.2 | 3.5 | - | - | 2 |
| Fatigue strength (ksi) (limit@ 500 million cycles) | 18 | 20 | 19 | - | 20 |
| Density (lb./in.3) | 0.095 | 0.098 | 0.097 | 0.099 | 0.096 |
| Melting range (˚F) (Approx.) | 1035- 1105 | 1000- 1105 | 960- 1100 | 945- 1200 | 1065- 1080 |
| Specific heat (Btu/lb. ˚F) | 0.23 | 0.23 | - | - | - |
| Coefficient of thermal expansion (in./in./ ˚F) | 11.8 | 11.7 | 11.5 | 11.7 | 10.3 |
| Thermal conductivity (Btu/fthr. ˚F) | 65.3 | 55.6 | 55.6 | 78.6 | 67.7 |
| Electrical conductivity (%IACS) | 29 | 23 | 23 | 25 | 31 |
| Modulus of elasticity (106 psi) | 10.3 | 10.3 | 10.3 | 11.9 | 10.3 |
| CHARACTERISTICS 1 – most desirable 5 – least desirable | A360 | A380 | A383 | A390 | A413 (A13) |
| Resistance to Hot Cracking | 2 | 2 | 1 | 4 | 1 |
| Pressure Tightness | 1 | 2 | 2 | 4 | 1 |
| Polishing | 3 | 3 | 3 | 5 | 4 |
| Fluidity | 2 | 2 | 1 | 1 | 1 |
| Corrosion Resistance | 2 | 4 | 3 | 3 | 2 |
| Machine-ability | 2 | 2 | 2 | 5 | 4 |
| Strength at Elev. Temp. | 3 | 2 | 2 | 3 | 2 |
| Anti-Die Soldering Tend. | 3 | 1 | 2 | 2 | 2 |
| Electroplating | 1 | 1 | 1 | 3 | 3 |
| Anodizing Appearance | 4 | 3 | 3 | 5 | 5 |
China Import and Export Fair
FAQ :
Q1: Wonder if you accept small orders?
A1: Do not worry. Feel free to contact us .in order to get more orders and give our clients more convener ,we accept small order.
Q2: Can you send products to my country?
A2: Sure, we can. If you do not have your own ship forwarder, we can help you.
Q3: Can you do OEM for me?
A3: We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.
Q4: What's your payment terms ?
A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.
Q5: How long is your production lead time?
A5:It depends on product and order qty. Normally, it takes us 15 days for an order with MOQ qty.
Q6: When can I get the quotation ?
A6: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.
|
|
